(1) It is equipped with independently R&D and designed skylight-specific aluminum profiles with a wall thickness of 1.8-2.5mm;(2) The span of a single sash can reach up to 1.6m, and the area can reach
Technical Parameters
(1) Installation method: External type
(2) Profile specification: 60×110×2mm
(3) Processing technology: Aluminum alloy seamless welding
(4) Glass configuration: 5G+12A+5G (standard configuration) or 8G+6A+8G
(5) Control method: Electric remote control, manual opening
(6) Opening range: 95% of the opening area can be opened
(7) Skylight standard accessories: Built-in motor, touch screen controller, remote control
(8) Intelligent optional accessories: Mobile phone remote control, solar power supply, rain sensor, electric screen window, electric sunshade
Equipment Details
(1) It is equipped with independently R&D and designed skylight-specific aluminum profiles with a wall thickness of 1.8-2.5mm;
(2) The span of a single sash can reach up to 1.6m, and the area can reach up to 2m²; it can be combined arbitrarily;
(3) Equipped with a built-in electric transmission system, with noise as low as 30 decibels;
(4) The service life of the motor can reach over 30,000 operations;
(5) Directly input 220V voltage and can be directly controlled by remote control;
(6) It has an instant braking function, which can immediately overcome the inertia of the power system.
